SAPPHIRE Pulse RX 570 4G

GPU
RX 570, 14 nm FinFET
4th Graphics Core Next (GCN)

Engine Clock
Up to 1284 MHz, Boost

Stream Processors
2048

Memory Size/Bus
4GB GDDR5/256-bit

Memory Clock
7000 MHz effective

Displays
Maximum 5 Outputs

Interface
PCI-Express 3.0

Resolution
DisplayPort: 5120×2880@60Hz
HDMI: 4096×2160@60Hz
DVI:2560×1600@60Hz
Output
1x DVI-D
2x HDMI
2x DisplayPort 1.4

BIOS Support
UEFI
API
OpenGL® 4.5
OpenCL 2.0
DirectX® 12
Shader Model 5.0
Game Index
1080p gaming
Sapphire Features
Dual-X Cooling
Long Life Dual Ball Bearing Fans
Intelligent Fan Control III
Quick Connect System
Long Life Capacitor
Back plateBlack
Diamond 4 Chokes
Fuse protection

AMD Features
Radeon™ VR Ready Premium
Radeon™ Software
Radeon™ FreeSync Technology
AMD LiquidVR™ Technology
4th Gen GCN Architecture
Radeon™ Chill
Radeon™ ReLive DirectX® 12 Technology
AMD Eyefinity Technology (Gaming)
AMD App Acceleration
AMD CrossFire™ Technology
AMD CrossFire™ (Bridgeless)
3rd Gen 14nm Process Technology
OpenCL 2.0
OpenGL 4.5
AMD PowerTune Technology
TrueAudio Next
Unified Video Decoder (UVD)
Video Code Engine (VCE)
Virtual Super Resolution
The Vulkan® API
Cooler Type
Dual-X Cooling Technology
Two ball bearing fan
Fan Quick Connect
Form Factor
2 Slots Occupied
230X125X40 Dimension/mm
Power Consumption
<180W
OS
Windows® 11, 10, Windows® 7, 64bit operating system required

System Requirement
500 Watt or greater power supply (Recommended)
1 x 8-pin Power Connector
PCI Express® compliant motherboard with one x16 graphics slot
